LED Downlights and Panel Lights: Types, Mounting and Where They Fit
An LED downlight is a ceiling light fitting that sends light downward into the room below it. It is either recessed into a false ceiling, so that only the trim is visible, or surface-mounted onto a solid ceiling. Vinayak Electricals, based in Marol, Andheri East, Mumbai, makes LED downlights and panel lights under the Vinayak LED name and holds BIS registration R-71026476 under IS 10322 for its LED down lights and panels.
What an LED downlight does
A downlight is a single compact fitting aimed at the floor or work surface below it. Because the light is directed rather than spread in all directions, several downlights are usually spaced across a ceiling to light a room evenly. A panel light works on the same idea but emits light from a flat, wider face, so one panel is normally used where a broad, even wash of light is wanted.
Recessed or surface-mounted
The mounting method is the first thing to settle, because it depends on the ceiling you have rather than on the fitting you prefer.
| Type | How it mounts | Ceiling needed | What is visible |
|---|---|---|---|
| Recessed | Sits inside a cut-out in the ceiling | A false ceiling with clear space above it | Only the trim ring and lens, flush with the ceiling |
| Surface-mounted | Screwed to the underside of the ceiling | Any ceiling, including a bare concrete slab | The whole body of the fitting, below the ceiling line |
Recessed fittings suit rooms that already have a false ceiling. Surface-mounted fittings suit older flats, shops and sheds where there is no false ceiling, and they can be changed later without cutting into the ceiling. Before ordering either type, confirm the depth available above the ceiling and the cut-out the fitting needs.
Where downlights and panels are used
Downlights are common in living rooms, bedrooms, passages and bathrooms at home, and in reception areas, cabins, shops and hotel corridors in commercial buildings. They suit these spaces because the fitting is small and can be spaced in a line or a grid to match the room. Panel lights are more common in offices, showrooms, educational institutions and larger shops, where a few flat panels light a wide area with fewer fittings.
The Vinayak LED downlight and panel products
Within the Vinayak LEDs range, these product pages cover downlights and panels:
The printed catalogue lists LED down lights of 3 W, 5 W and 6 W (codes 1010 to 1012), Ultra Prime, slim, aluminium casting and super slim panels from 8 W to 22 W (codes 1021 to 1035), and big, border-less and concealed surface LED lights from 6 W to 22 W (codes 1003 to 1008), with their MRPs. Ask for cut-out size, colour temperature and dealer pricing through the contact page before ordering. The Vinayak LED range also includes a flood light, a street light, tube fittings and bullet LEDs, a 0.5W night lamp and the LED Lamp Sumo; see the LED light manufacturer hub for the rest of the LED range.
Related fittings on this site
This page covers ceiling downlights and panels. For the VIZA Royal 4-module LED foot lights that fit a standard modular plate on staircases and corridors, see the foot light page. For the diffused LED down lights and slim foot lights in 2-module and 4-module scenery patterns, see the diffused light page.
How to buy VIYONA downlights and panels
These fittings are made by Vinayak Electricals in Mumbai and sold through its dealers and distributors rather than direct, so ask a local dealer for stock and dealer pricing, or send an enquiry through the contact page. Electrical retailers who want to stock the range can read how to become a dealer or distributor, and the full lighting line is in the e-catalogue.
