1 module and 2 module switches and sockets, with codes and prices
Key takeaways
- 1M: most 1 way and 2 way switches, bell pushes, the 6A 2 pin socket and 1M regulators.
- 2M: 3 pin and 16A sockets, universal sockets, 32A DP switches and 2M regulators.
- Some 20A switches come in both: KEMPS K106 is 1M (₹107), K111 is 2M (₹156).
- Add up the modules to size the plate: 3 switches + a 2 way + a 16A socket = 6M.
- A 1M or 2M VIZA Cherry plate is ₹65; a 6M plate ₹140.
What do 1 module and 2 module mean?
A modular plate is a frame with a fixed number of slots, counted in modules. A 1 module item fills one slot; a 2 module item fills two side by side. A 6M plate therefore holds six 1M switches, or three 2M sockets, or any mix that adds up to six.
The module count is printed in our catalogue for every code, so a board can be planned on paper before anything is bought.
1 module switches and sockets
Most switches are 1M. From our current catalogue:
1 module items by MRP
Printed MRPs from our current catalogue, as published in our product guides. Bars to scale; wire and labour are extra.
The 6A 2 pin socket is the one socket that fits in a single module; anything with three pins or a 16A rating takes two.
| Item | Modules | Example code and MRP |
|---|---|---|
| 10A / 10AX 1 way switch | 1M | VIZA V541 ₹56; KEMPS K101 ₹65 |
| 10AX 2 way switch | 1M | KEMPS K102 ₹105 |
| 6A 2 pin socket | 1M | VIZA V262 ₹78 |
| 6A 3 pin socket | 2M | KEMPS K192 ₹110 |
| 16A socket | 2M | VIZA V263 ₹160 |
| Universal 6A and 16A socket | 2M | KEMPS K193 ₹205 |
| 32A DP switch | 2M | VIZA V1250 ₹330; KEMPS K516 ₹392 |
| Fan regulator | 1M or 2M | VIZA V278 1M ₹360; V279 2M ₹425 |
2 module switches and sockets
Sockets with three pins, 16A sockets, universal sockets and 32A DP switches are 2M:
2 module items by MRP
Printed MRPs from our current catalogue, as published in our product guides. Bars to scale; wire and labour are extra.
A geyser or AC point is usually a 32A DP switch plus a 16A socket: 4 modules for one appliance.
Most switches, bell pushes, the 6A 2 pin socket.
3 pin and 16A sockets, DP switches.
Three switches, a 2 way and a 16A socket make 6M.
Same size for both: 6M plate, 6M box.
20A switches: 1 module or 2 module
Some heavier switches come in both widths, so check the code against the space on the plate:
- KEMPS K106 20AX 1 way: 1M, ₹107.
- KEMPS K111 20AX 1 way: 2M, ₹156.
- VIZA V1246 20A 1 way: 2M, ₹145; V1248 with indicator, 2M, ₹160.
Planning a board around a 20A switch? Confirm the module width of the exact code before you fix the plate size.
Counting modules to size a plate
Add the modules, then choose the next plate size up if you want a spare slot. Our price guide's bedroom board:
- 3 × V541 10A 1 way switch: 3 × 1M
- 1 × V542 10A 2 way switch: 1M
- 1 × V264 16A socket: 2M
That is 6M, so a 6M plate; the whole board is ₹537 at MRP in VIZA Cherry white. Plates come in 1M to 18M; our plate size guide lists every size.
Plate prices by size
The plate price rises with its module count. In VIZA Cherry white:
VIZA Cherry white plate MRP by size
Printed MRPs from our current catalogue, as published in our product guides. Bars to scale; wire and labour are extra.
A 1M or 2M plate costs the same, so a single 2M socket on its own plate is no dearer than a 1M switch. Behind each plate goes a concealed box of the same size; see our concealed box guide.
Where we supply
Made at our works in Marol, Andheri East, and sold through dealers and distributors across Maharashtra. Each region has its own page with distances, local examples and how to buy:
- South and Central Mumbai
- Western suburbs
- Eastern suburbs
- Vasai-Virar, Mira-Bhayandar and Palghar
- Thane district
- Navi Mumbai and Panvel
- Konkan
- Pune
- Kolhapur, Sangli, Satara and Solapur
- North Maharashtra
- Marathwada
- Vidarbha
For the whole state on one page, see where we supply in Maharashtra. We deliver all over India for orders placed through our office, in full boxes.
From our catalogue: KEMPS Orchid K141 10AX 1 way switch, VIYONA royal ABS spike guard and VIYONA classic ABS socket spike guard.
FAQs
What is a 1 module switch?
What is a 2 module socket?
Is a 16A socket 1 module or 2 module?
Is a 32A DP switch 2 module?
How many modules does a bedroom board need?
Do 1M and 2M plates cost the same?
