Concealed boxes for modular switches: sizes, prices and surface boxes
Key takeaways
- A concealed box sits in the wall behind the plate; its size must match the plate, 1M to 18M.
- VIZA concealed unbreakable boxes: ₹50 (1/2M) to ₹230 (18M); the 6M is ₹118.
- A G.I. sheet metal box is sturdier and costs more: ₹170 for 6M (V624).
- Wiring on the wall? A VIZA surface gang box (₹65 for 1 way to ₹265 for 18 way) replaces the concealed box.
- On a renovation, a sound box already in the wall can usually stay.
What is a concealed box?
Every modular switch board has three parts you pay for separately: the modules (switches, sockets, regulators), the plate with its frame, and the box in the wall. The concealed box is set into the plaster when the wiring is laid, so the plate finishes flush with the wall.
Its size is counted in modules, the same as the plate: a 6M plate needs a 6M box. Get the box wrong at the wiring stage and the plate will not fit later, which is why the box is chosen before the switches.
Concealed box sizes and prices
Our VIZA concealed unbreakable box comes in eight sizes, from 1/2M to 18M. These are printed MRPs from our current catalogue:
VIZA concealed unbreakable box MRP by size
Printed MRPs from our current catalogue, as published in our product guides. Bars to scale; wire and labour are extra.
The 8M comes in two shapes: horizontal (₹130) for a long board and square (₹145) for a 4 by 2 arrangement. Match the box to the plate shape you will fit.
| Box | Sizes | MRP |
|---|---|---|
| VIZA concealed unbreakable box | 1/2M to 18M | ₹50 to ₹230 |
| G.I. sheet metal box | 6M (V624) | ₹170 |
| VIZA surface gang box | 1 way to 18 way | ₹65 to ₹265 |
| MCB boxes (separate range) | 1 way to 18 way | ₹40 to ₹1,410 |
Unbreakable plastic or G.I. sheet metal?
- Unbreakable plastic: light, does not rust, and the usual choice for homes and offices. 6M ₹118.
- G.I. sheet metal: galvanised steel, sturdier against rough handling on site. 6M ₹170 (V624).
Both take the same plates. On most home jobs the plastic box is enough; a contractor working with heavy wall chasing may prefer metal.
Whichever you choose, the box must sit square and flush. A box set crooked in the plaster makes the plate rock and the screws strip.
A 6M plate needs a 6M box; choose it before the switches.
Unbreakable plastic, 1M to 18M, ₹50 to ₹230.
G.I. box for rough sites: 6M ₹170.
Surface gang boxes from ₹65 for wall wiring.
Surface wiring: the surface gang box
Where wires run on the wall rather than inside it, there is nothing to conceal a box in. A VIZA smart modular surface gang box sits on the wall instead and takes the same modules and plates, from ₹65 for 1 way (V641) to ₹265 for 18 way (V649).
Our guide to wiring systems compares surface and concealed wiring.
What the box adds to a board
Our switch board price guide prices three VIZA Cherry boards with and without the concealed box. The box adds ₹118 to ₹170 to each:
VIZA Cherry boards with the concealed box
Printed MRPs from our current catalogue, as published in our product guides. Bars to scale; wire and labour are extra.
Across a 2BHK in KEMPS, the concealed boxes come to ₹710 of a ₹6,302 parts bill.
Renovating: can the old box stay?
On a renovation, a sound modular box already in the wall can usually stay, which takes the box off the bill. Check that it is the right size for the new plate, sits square and flush, and is not cracked or loose.
If the old wall has a non-modular box, the wall has to be opened to fit a modular one. Our switch replacement guide covers the safe way to work on a board.
Switch off the MCB and prove the circuit dead before opening any board.
Where we supply
Made at our works in Marol, Andheri East, and sold through dealers and distributors across Maharashtra. Each region has its own page with distances, local examples and how to buy:
- South and Central Mumbai
- Western suburbs
- Eastern suburbs
- Vasai-Virar, Mira-Bhayandar and Palghar
- Thane district
- Navi Mumbai and Panvel
- Konkan
- Pune
- Kolhapur, Sangli, Satara and Solapur
- North Maharashtra
- Marathwada
- Vidarbha
For the whole state on one page, see where we supply in Maharashtra. We deliver all over India for orders placed through our office, in full boxes.
From our catalogue: KEMPS Orchid K142 10AX 2 way switch, VIYONA Royal & Decent 2 pin top (male and female) and VIYONA classic ABS socket spike guard USB.
